–3V（最小值）至Vuser（最大值）有關產品標準和一般規范，請參閱附錄A.64在存在嚴重RF干擾（IC 801-3，10V/m）的情況下，精度可能會降低到±1%FS。PACSystems*RX3i系統手冊第12節GFK-2314T 2019年9月模擬輸出模塊452 10.3.12.1熱降額，電流模式：ALG708模塊IC695ALG704沒有熱降額。模塊IC695ALG008在電壓模式下沒有熱降額。電流模式下模塊IC695ALG008的熱降額如圖305所示。圖305：ALG708在選定電壓水平下的熱降額曲線（僅限電流模式）10.3.13配置：ALG704和ALG708 10.3.13.1模塊參數參數默認描述輸出參考地址%AQxxxxx此模塊輸出數據的起始地址。這默認為下一個可用的%AQ塊。輸出參考長度ALG004:8用于此模塊輸出數據的單詞數。無法更改此參數。ALG708:16輸出命令反饋參考地址%AIxxxxx此模塊命令反饋數據的說明地址。配置非零長度后，默認為下一個可用%AI地址。輸出命令反饋長度0用于此模塊的命令反饋數據的單詞數。長度默認為0。它可以設置為8或16，具體取決于所配置的模塊類型。診斷參考地址%Ixxxxx通道診斷狀態數據的起始地址。這默認為下一個可用的%I塊。50 51 52 53 54 55 56 57 59 60 1 2 3 4 5 6 7 8環境（攝氏度）通道Vuser=26.5V此模塊的狀態數據短路。這默認為下一個可用的%I塊。模塊狀態參考長度0只讀。模塊狀態數據所需的位數（0或32）。默認值為0，這意味著模塊狀態數據的映射被禁用。將其更改為非零值以啟用模塊狀態數據映射。10.3.13.1.1模擬輸出命令反饋模塊將從CPU接收的模擬輸出數據的副本返回到其相應的通道模擬輸入共享存儲器中。可以監控輸出反饋，以檢查發送到通道的值。數據采用與每個通道的輸出數據相同的縮放格式。在正常操作期間，該反饋數據應與模塊輸入的一次或多次PLC掃描后的實際輸出數據相匹配。在故障、斜坡、超范圍和箝位條件下，模擬輸出數據可能與命令輸出不同。10.3.13.1.2過高溫度如果啟用了過高溫度，如果該模塊的內部溫度對于同時打開的輸出數量而言過高，則模塊會生成過高溫度警報。
– 3V (minimum) to Vuser (maximum) For product standards and general specifications, refer to Appendix A. 64 In the presence of severe RF interference (IC 801-3, 10V/m), accuracy may be degraded to ±1% FS. PACSystems* RX3i System Manual Section 12 GFK-2314T Sept. 2019 Analog Output Modules 452 10.3.12.1 Thermal Derating, Current Mode: ALG708 Module IC695ALG704 has no thermal derating. Module IC695ALG708 has no thermal derating in voltage mode. Thermal derating for module IC695ALG708 in current mode is displayed in Figure 305. Figure 305: Thermal Derating Curves for ALG708 at selected Voltage Levels (Current Mode only) 10.3.13 Configuration: ALG704 and ALG708 10.3.13.1 Module Parameters Parameter Default Description Outputs Reference Address %AQxxxxx Starting address for the output data of this module. This defaults to the next available %AQ block. Outputs Reference Length ALG704: 8 The number of words used for the output data of this module. This parameter cannot be changed. ALG708: 16 Output Command Feedback Reference Address %AIxxxxx Stating address for the command feedback data of this module. This defaults to the next available %AI address after a non-zero length is configured. Output Command Feedback Length 0 The number of words used for the command feedback data of this module. Length defaults to 0. It can be set to 8 or 16, depending on the module type being configured. Diagnostic Reference Address %Ixxxxx Starting address for the channel diagnostics status data. This defaults to the next available %I block. 50 51 52 53 54 55 56 57 58 59 60 1 2 3 4 5 6 7 8 Ambient (Degrees C) Channels Vuser = 26.5V Shorted the status data of this module. This defaults to the next available %I block. Module Status Reference Length 0 Read Only. The number of bits (0 or 32) required for the Module Status data. Default is 0, which means mapping of Module Status data is disabled. Change this to a non-zero value to enable Module Status data mapping. 10.3.13.1.1 Analog Output Commanded Feedback The module returns a copy of the analog output data received from CPU in its corresponding channel analog input shared memory. Output Feedback can be monitored to check the values being sent to the channels. The data is in the same scaled format as the output data for each channel. During normal operation, this feedback data should match the actual output data after one or more PLC scans of module inputs. During faults, ramping, over-range, and clamping conditions, the analog output data may differ from the commanded output. 10.3.13.1.2 Over-Temperature If Over-Temperature is enabled, the module generates an Over-Temperature alarm if the internal temperature of this module is too great for the number of outputs that are on at the same time.
