產品內容介紹
YOKOGAWA CP345-S1處理器板模塊
輸出端接組件輸入輸出或帶配電的輸出（用戶通過終端組件上的終端提供）。在兩種配置中，當FBM輸出打開時，繼電器線圈通電，繼電器觸點從常閉（NC）位置切換到常開（NO）位置。FBM+24 V dc輔助電源用于為繼電器線圈通電。帶配電裝置的終端組件有一個專用接線板，用于連接外部電源，并在終端組件內部分配至每個輸出通道。電源線或正極熔斷；電源的中性或負極連接到磁場。16通道，開關（每個通道都有保險絲保護）冗余電源15至60 V dc（外部電源），最大電流為2 A，配電組隔離由終端組件提供最大電流限制為每8通道12 A?；? A電流的輸出電感負載限制。電流每減少2倍，電感限制增加4倍。對于高于規定限值的電感負載，直流電感負載需要緩沖二極管，交流電感負載需要MOV（金屬氧化物變阻器）。二極管額定電流必須等于最大負載電流，額定電壓必須等于最大電源電壓的1.3倍。MOV的額定值必須為120 V ac，額定電流必須等于最大負載電流。（b） PA是聚酰胺，額定溫度為-20至+70°C（-4至+158°F）。（c） c=帶有壓縮端子的TA。RL=帶環形接線片端子的TA。刀具有壓縮端子。（d） 電纜零件號見表2。（e） 見表1終端組件認證定義。（f） 有關繼電器觸點額定值的更多詳細信息，請參見第15頁。（g） 這是刀斷開結構。刀片和測試插座僅用于電路驗證。刀式斷開裝置不適用于中斷負載。斷開電路前必須切斷電源。
終端組件認證
類型認證類型1 TA是UL/UL-C列出的適用于I級的TA；A-D組；2類溫度代碼T4危險場所。它們是DEMKO認證的EEx nA IIC T4，用于2區潛在爆炸性環境。2類TA是UL/UL-C列出的相關設備，用于提供I級非易燃現場電路；A-D組；當連接到指定的200系列FBM和滿足《標準和緊湊型200系列子系統用戶指南》（B0400FA）中規定的實體參數約束的現場電路時，第2類危險位置。它們還被DEMKO認證為為IIC組2區潛在爆炸性環境提供現場電路的相關設備。如果客戶提供的設備滿足2類限制，則現場電路也屬于2類限制能量（60 V dc、30 V ac、100 VA或更少）。如果客戶提供設備滿足2級限制，則所有現場電路都屬于2類有限能量（60 V dc、30V ac和100 VA或更低）。類型5 TA及其現場電路僅用于普通（非危險）位置。P/PVC電纜裝配聚氨酯外護套和半硬質PVC一次導體絕緣溫度范圍：-20至+70°C（-4至158°F）。4H P/PVC（a）（b）（b。類型4 LSZH（c）（c）低煙無鹵或低煙無鹵素（LSZH）是用于電纜護套的材料分類。LSZH由熱塑性或熱固性化合物組成，當暴露于高熱源時，它們會釋放出有限的煙霧和無鹵素。溫度范圍：-40至+105°C（-40至+221°F）。
The output termination assemblies
come in either output or output with power distribution (usersupplied via terminals on the termination assembly). In both configurations, when the FBM output is on, the relay coil is energized and the relay contact is switched from normally closed (NC) position to the normally open (NO) position. The FBM +24 V dc auxiliary power supply is used to energize the relay coil. Termination assemblies with power distribution have a dedicated terminal block which provides a connection to externally supplied power and distributed internally on the termination assembly to each of the output channels. The line or positive side of the supply is fused; the neutral or negative side of the supply is connected to the field.16 channel, switch (each channel is protected - fused) Redundant power 15 to 60 V dc (externally sourced) at 2 A maximum with power distribution Group isolation provided by termination assembly Maximum current is limited to12 A per 8 channels. Output inductive load limits based on current of 2 A. Inductance limit increases by a factor of 4, for each factor of 2 reduction in current. For an inductive load above stated limits, a snubber diode is required for a dc inductive load or a MOV (metal oxide varistor) is required for an ac inductive load. Diode current rating must be equal to the maximum load current and voltage rating equal to 1.3X maximum supply voltage. MOV must be rated for 120 V ac use and current rating must be equal to maximum load current. (b) PA is polyamide rated from -20 to +70°C (-4 to +158°F). (c) C = TA with compression terminals. RL = TA with ring lug terminals. Knife has compression terminals. (d) See Table 2 for cable part numbers. (e) See Table 1 Termination Assembly certification definitions. (f) See Page 15 for more detail on the relay contact rating. (g) This is knife disconnect construction. Knives and test sockets provided for circuit validation only. Knife disconnects are not rated for interrupting loads. Power must be removed before disconnecting circuit.
Certifications for Termination Assemblies
Type Certification Type 1 TAs are UL/UL-C listed as suitable for use in Class I; Groups A-D; Division 2 temperature code T4 hazardous locations. They are DEMKO certified EEx nA IIC T4 for use in Zone 2 potentially explosive atmospheres. Type 2 TAs are UL/UL-C listed as associated apparatus for supplying non-incendive field circuits Class I; Groups A-D; Division 2 hazardous locations when connected to specified 200 Series FBMs and field circuits meeting entity parameter constraints specified in Standard and Compact 200 Series Subsystem User’s Guide (B0400FA). They are also DEMKO certified as associated apparatus for supplying field circuits for Group IIC, Zone 2 potentially explosive atmospheres. Field circuits are also Class 2 limited energy (60 V dc, 30 V ac, 100 VA or less) if customersupplied equipment meets Class 2. Type 4 All field circuits are Class 2 limited energy (60 V dc, 30 V ac, 100 VA or less) if customer-supplied equipment meets Class 2 limits. Type 5 The TA and its field circuitry are for use in only ordinary (non-hazardous) locations.P/PVC cable assembles polyurethane outer jacket and semi-rigid PVC primary conductor insulation temperature range: -20 to + 70°C (-4 to 158°F). Type 4H P/PVC(a)(b) (b) Type 4H cables are used to reduce voltage drop in long (greater than 5 m (15 ft)) cable run applications. Type 4 LSZH(c) (c) Low smoke zero halogen or low smoke free of halogen (LSZH) is a material classification used for cable jacketing. LSZH is composed of thermoplastic or thermoset compounds that emit limited smoke and no halogen when exposed to high sources of heat. Temperature range: -40 to +105°C (-40 to +221°F).
產品優勢
1：國外專業的供貨渠道，具有價格優勢
2：產品質量保證，讓您售后無憂
3：全國快遞包郵
4：一對一服務
公司主營范圍簡介
PLC可編程控制器模塊，DCS卡件，ESD系統卡件，振動監測系統卡件，汽輪機控制系統模塊，燃?xì)獍l(fā)電機備件等，優勢品牌：Allen Bradley、BentlyNevada、ABB、Emerson Ovation、Honeywell DCS、Rockwell ICS Triplex、FOXBORO、Schneider PLC、GE Fanuc、Motorola、HIMA、TRICONEX、Prosoft等各種進口工業零部件、歐美進口模塊。
產品廣泛應用于冶金、石油天然氣、玻璃制造業、鋁業、石油化工、煤礦、造紙印刷、紡織印染、機械、電子制造、汽車制造、塑膠機械、電力、水利、水處理/環保、鍋爐供暖、能源、輸配電等等
