在電動汽車使用充滿電的電池之前，充電電路需要將電網的交流電轉為高壓直流電，同時監測和控制整個充電過程。傳統的230V插座足以在一個晚上通過小型電動汽車的充電器將汽車充滿電。家用插座提供最高2.3kW的功率，整個充電時間需要數小時。公共和快速充電站的功率超過100kW，所以充電速度比較快，大約一個小時就可充滿一個85kWh的電池。仍在開發中的超大功率充電站可以處理高達400kW的功率。
12P2532X162-233A可編程模塊,KJ3222X1-BA1配置教程這樣可以將充電過程縮短到大約十五分鐘，很適合長途旅行中在短暫的休息時為汽車充電。所有主要的充電站都用直流電為電動汽車充電。目前的標準電壓為400V，但將來可能會提升至800V。即使認為在家庭環境中的直流電是安全的，電壓到如此之高也是會致命的，因此整個系統對可靠性的要求相對的也較高。
這需要牢固的插頭連接以及可靠的電子安全系統。為了達到這個目的，汽車電池管理系統和充電站之間要隨時保持通信狀態。只有當充電器牢固地插在充電插座上，并同時發出恒定的「ok」信號時才會開始充電。如果信號中斷，充電站會立即斷開充電連接。RECOM RAC05-xxSK/480可將480VAC的相 -相電壓轉換為5或15V DC。5W轉換器的工作溫度為-40°C至+80°C以上。
RAC05-xxSK/480 AC/DC轉換器的輸入電壓最高可達528VAC，因此很容易在三相供電系統的任意兩相之間直接取電工作。通過RAC05-xxSK/480 AC/DC轉換器可得到一個4KVAC隔離的5VDC或15VDC，功率為5W的直流低電壓來為握手協議監控電路供電。
不僅充電站需要徹底的監控，對鋰電池本身也需要不斷地觀察。先進的鋰離子電池通常被分成幾個小模組。每個模組的電流、電壓和溫度需要分別監控，以確保充電過程中電池的安全。如果有一個模組有故障時必須可以單獨關閉它，以讓正常運行的模組繼續供電。復雜的電池管理系統對延長電池壽命和電池保護是至關重要的。
為此RECOM開發了一系列用于電動汽車電池管理的1W DC/DC轉換器。每個電池模組都需要屬于自己的DC/DC轉換器來為CAN總線和電壓監測電路進行隔離供電。這款DC/DC轉換器的隔離高達5.2KVDC，且出廠時全部通過隔離耐壓測試。
maintainability verification: use indicator light to indicate, locate the fault point, and facilitate maintenance; If the reliability operation is verified, the operation mileage shall not be less than 10W km, and the operation time shall not be less than 1 year;
6. Other requirements: for example, for power supply interruption, drop and other requirements, the general module power supply design is difficult to meet the 10ms interruption requirements, especially for low-voltage input products, it is necessary to increase the peripheral input and output capacitance to meet the needs of customers; For example, for the short-circuit protection measures of the battery, anti reflection diodes or mechanical design are generally used to avoid this failure.
3、 Power supply selection of on-board electronic equipment
As one of the methods to prevent fault spreading, isolated power supply plays an important role in on-board electronic equipment; However, in the process of vehicle operation, there are various states, such as violent vibration state;
