Install/remove jumpers on headers according to the Jumper Settings in this
chapter and as required for your particular application.
? Jumpers on header J1 affect 187Bug operation as listed in Jumper
Settings. The default condition is with all eight jumpers installed
? A jumper installed/removed on header J2 enables/disables the
system controller function of the MVME187.
? Install jumpers on headers J7 and J8 to configure serial port 4 to
use clock signals provided by the TRXC4 and RTXC4 signal lines.
2 Configure adapters and transition modules according to the MVME712X
transition module user's manuals.
3 Ensure that EPROM devices are properly installed in their sockets.
? Factory configuration is with two EPROMs installed for the
MVME187Bug debug monitor, in sockets XU1 and XU2. Now that the MVME187 module is ready for installation, prepare
the system chassis and determine slot assignments (for peripherals,
transition modules, etc.) as follows:Inserting or removing modules while power is applied
could result in damage to module components.
Dangerous voltages, capable of causing death, are
present in this equipment. Use extreme caution when
handling, testing, and adjustingTurn all power OFF to chassis and peripherals.
2 Disconnect AC power cable from source.
3 Remove chassis cover as shown in the user's manual for your
particular chassis or system.
4 Remove the filler panel(s) from the appropriate card slot(s) at the front
and rear of the chassis (if the chassis has a rear card cage).
If the MVME187 is configured as
system controller:
If it is not configured as system
controller:
It must be installed in the
left-most card slot (slot 1) to
correctly initiate the bus-grant
daisy-chain and to have proper
operation of the IACK-daisy-chain
driver.
It may be installed in any doubleheight unused card slot. Installing the Hardware
This section covers
? Installation of the MVME187 into a VME chassis
? Overview and installation of transition modules and adapter
boards
? Connection of peripheral equipment such as console
terminals, optional SCSI drives, and serial or parallel printers
