GE 193X278AAG03繼電器板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
GE 193X278AAG03 繼電器板（Relay Board） 是 GE 193X 系列中用于工業控制系統的關鍵輸出模塊，主要功能是實現邏輯控制信號與高功率執行元件之間的電氣隔離與聯動控制。該模塊被廣泛用于電力系統、自動化控制系統和驅動系統中，用以控制馬達、報警設備、斷路器等執行單元。
一、產品基本信息
| 項目 | 內容 |
|---|---|
| 產品型號 | 193X278AAG03 |
| 產品名稱 | 繼電器板（Relay Board） |
| 制造商 | GE（General Electric） |
| 系列 | 193X 控制系統模塊系列 |
| 安裝方式 | 插卡式，安裝于193X主控機架中 |
二、主要功能
| 功能模塊 | 描述 |
|---|---|
| 繼電器輸出 | 接收來自控制邏輯（如PLC或檢測模塊）的信號，控制高壓/高電流回路通斷 |
| 信號隔離 | 提供控制電路與負載電路之間的電氣隔離，保護核心控制器件 |
| 狀態指示 | 一般帶有LED或信號指示燈，顯示繼電器動作狀態 |
| 多通道控制 | 支持多個獨立通道控制（視版本而定），實現多點輸出 |
| 過流保護 | 內建熔斷或過載保護功能，防止異常電流損壞板卡 |
三、技術參數（典型）
| 參數類別 | 參數說明 |
|---|---|
| 控制電壓 | 通常為5V DC 或 24V DC |
| 繼電器類型 | 電磁繼電器（DPDT 或 SPDT，具體以實物為準） |
| 輸出容量 | 每通道可支持最高250V AC，5A負載（視規格而定） |
| 通道數 | 多通道設計（如4/8通道），具體型號決定 |
| 響應時間 | < 10ms（典型繼電器響應速度） |
| 絕緣耐壓 | 控制端與負載端間隔離耐壓 ≥1500V |
| 工作環境 | 溫度：-20°C ~ +60°C，濕度：＜95%，無凝露 |
英文資料：
The GE 193X278AAG03 Relay Board is a key output module used in industrial control systems in the GE 193X series. Its main function is to achieve electrical isolation and linkage control between logic control signals and high-power execution components. This module is widely used in power systems, automation control systems, and drive systems to control execution units such as motors, alarm devices, circuit breakers, etc.
1、 Basic Product Information
Project Content
Product model 193X278AAG03
Product Name: Relay Board
Manufacturer GE (General Electric)
Series 193X Control System Module Series
Installation method: plug-in card, installed in the 193X main control rack
2、 Main functions
Function module description
Relay output receives signals from control logic (such as PLC or detection module) to control the on/off of high voltage/high current circuits
Signal isolation provides electrical isolation between control circuits and load circuits, protecting core control devices
The status indicator generally has LED or signal indicator lights to display the relay action status
Multi channel control supports multiple independent channel controls (depending on the version) to achieve multi-point output
The overcurrent protection has built-in fuse or overload protection function to prevent abnormal current from damaging the board
3、 Technical parameters (typical)
Parameter Category Parameter Description
The control voltage is usually 5V DC or 24V DC
Relay type: Electromagnetic relay (DPDT or SPDT, subject to actual product)
Output capacity: Each channel can support up to 250V AC, 5A load (depending on specifications)
Number of channels: Multi channel design (such as 4/8 channels), specific model to be determined
Response time<10ms (typical relay response speed)
Isolation withstand voltage between insulation withstand voltage control terminal and load terminal ≥ 1500V
Working environment temperature:- 20 ° C~+60 ° C, humidity:<95%, no condensation
2.產 品 展 示
