Yaskawa CACR-SR01AC1ERY102伺服放大器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Yaskawa CACR-SR01AC1ERY102 是一款伺服放大器，廣泛應用于工業自動化控制系統中，專門用于驅動伺服電機并提供高精度的運動控制。伺服放大器在整個伺服系統中起到關鍵作用，負責接收控制信號，并將其轉換為電機驅動電流，以實現電機的精確控制。
主要功能與特點
高精度控制:
- 位置控制：CACR-SR01AC1ERY102 能夠通過精確的信號處理，實現伺服電機的位置控制，適合需要高精度定位的應用。
- 速度控制：放大器能夠根據控制信號調節電機的轉速，確保系統在各種工況下穩定運行。
- 力矩控制：支持對電機輸出力矩的精確控制，滿足工業設備對力矩的嚴格要求。
先進的反饋系統:
- 閉環控制：采用閉環反饋機制，通過實時監控電機狀態，自動調整輸出，減少誤差，提升控制精度。
- 編碼器兼容性：能夠與高精度編碼器結合使用，確保電機的精確響應和位置跟蹤。
高效率與低能耗:
- 節能設計：放大器采用高效電能轉換技術，降低能源消耗，同時保證設備的高效運行。
- 低發熱：設計上注重減少運行中的發熱量，有助于延長設備的使用壽命并提高系統穩定性。
多重保護功能:
- 過流保護：內置過流保護功能，當電流超出設定范圍時，自動切斷輸出，保護系統安全。
- 過壓保護：監測輸入電壓，防止電壓過高對放大器和電機造成損害。
- 過熱保護：具備溫度監控功能，當溫度超出安全范圍時，自動采取保護措施。
兼容性與靈活性:
- 廣泛兼容性：適用于多種型號的伺服電機，能夠與不同的工業控制系統輕松集成。
- 標準接口：采用標準化接口設計，便于與其他工業設備的連接與通信。
高可靠性與耐用性:
- 工業級設計：采用高質量工業級元件，能夠在惡劣的工業環境中穩定運行。
- 抗干擾能力：設計上注重抗電磁干擾能力，確保系統在復雜電磁環境下的正常運行。
英文資料：
Yaskawa CACR-SR01AC1ERY102 is a servo amplifier widely used in industrial automation control systems, specifically designed to drive servo motors and provide high-precision motion control. The servo amplifier plays a crucial role in the entire servo system, responsible for receiving control signals and converting them into motor drive currents to achieve precise control of the motor.
Main functions and features
High precision control:
Position control: CACR-SR01AC1ERY102 can achieve precise signal processing to control the position of servo motors, suitable for applications that require high-precision positioning.
Speed control: The amplifier can adjust the motor speed according to the control signal to ensure stable operation of the system under various working conditions.
Torque control: supports precise control of motor output torque, meeting the strict requirements of industrial equipment for torque.
Advanced feedback system:
Closed loop control: adopting a closed-loop feedback mechanism, by monitoring the motor status in real time, automatically adjusting the output, reducing errors, and improving control accuracy.
Encoder compatibility: It can be used in conjunction with high-precision encoders to ensure precise response and position tracking of the motor.
High efficiency and low energy consumption:
Energy saving design: The amplifier adopts high-efficiency electric energy conversion technology to reduce energy consumption while ensuring the efficient operation of the equipment.
Low heat generation: The design focuses on reducing the amount of heat generated during operation, which helps to extend the service life of the equipment and improve system stability.
Multiple protection functions:
Overcurrent protection: Built in overcurrent protection function, automatically cuts off the output when the current exceeds the set range, protecting the system safety.
Overvoltage protection: Monitor input voltage to prevent damage to amplifiers and motors caused by high voltage.
Overheating protection: equipped with temperature monitoring function, automatically taking protective measures when the temperature exceeds the safe range.
Compatibility and flexibility:
Wide compatibility: Suitable for multiple models of servo motors, it can be easily integrated with different industrial control systems.
Standard interface: Adopting standardized interface design to facilitate connection and communication with other industrial equipment.
High reliability and durability:
Industrial grade design: Using high-quality industrial grade components, it can operate stably in harsh industrial environments.
Anti interference capability: The design emphasizes the ability to resist electromagnetic interference, ensuring the normal operation of the system in complex electromagnetic environments.
2.產 品 展 示
